12V 4.2kW z10 (IS1089, MS117)
MAHLE Webkatalog
Letrika Webkatalog
MAHLE Ersatzteilliste
Letrika Ersatzteilliste
Gebrauchsanweisung
Letrika Webkatalog
MAHLE Ersatzteilliste
Letrika Ersatzteilliste
Gebrauchsanweisung
Haben Sie Fragen?
683 € 538 €
Verfügbar in 2 Werktagen i Unser Lieferant hat diesen Artikel auf Lager, den wir innerhalb der vorgegebenen Zeit besorgen können. Bestellungen, die außerhalb der Geschäftszeiten aufgegeben werden, werden am nächsten Werktag bearbeitet.
Versandkostenrechner
Bestellschlusszeit:
GLS: 15:00 / UPS: 12:30
11.131.300 AZF4577 MS117 MAHLE (Letrika, Iskra) Anlasser (11131300)
Ähnliche Produkte
Wir haben andere Produkte gefunden, die Ihnen gefallen könnten!
-
DEM608910 ADI Anlasser12V 4.0 kW z10
Referenznummern
| CASE | 91902C1, A162469, A187728 |
|---|---|
| CUMMINS | 01912347, 2347, 3920328 |
| DELCO REMY | 10461645 |
| DENSO | 1280004340, 1280005330, 1280005331, 1280009800, 1280009801, 280007430, 280007431 |
| DIXIE | S8098 |
| LESTER | 17353, 17634 |
| MAHLE (Letrika, Iskra) | IS1089, 11131532, AZF4138, 11131300, AZF4577, MS117 |
| SPAREX | 36209 |
| WILSON | 91295060 |
Kompatibilität
| Hersteller | Modell | Typ | Motor | Leistung | Baujahr |
|---|---|---|---|---|---|
| CASE | COMBINES | 1620 | D358/436/466 | 1985.01-1992.01 | |
| CASE | COMBINES | 1640 | D436/466 | 1985.01-1992.01 | |
| CASE | COMBINES | 1644 | All | 1993.01-1995.01 | |
| CASE | COMBINES | 1666 | All | 1993.01-1997.01 | |
| CASE | COMBINES | 1668 | All | 1993.01-1997.01 | |
| CASE | COMBINES | 1670 | DT466C | 1989.01-1991.01 | |
| CASE | COMBINES | 1680 | D436/DT466 | 1985.01-1992.01 | |
| CASE | COMBINES | 1688 | - | 1992.01-1994.01 | |
| CASE | COMBINES | 1690 | DT466C | 1985.01-1992.01 | |
| CASE | COMBINES | 2144 | - | 1994.01-1996.01 | |
| CASE | COMBINES | 2166 | - | 1994.01-1996.01 | |
| CASE | COMBINES | 2188 | - | 1994.01-1996.01 | |
| CASE | COMBINES | 2366 | - | 1997.01- | |
| CASE | COTTON PICKERS | 1822 | 6-590/6-830 | 1986.01-1992.01 | |
| CASE | COTTON PICKERS | 1844 | 6-590/6-830 | 1986.01-1992.01 | |
| CASE | COTTON PICKERS | 2055 | 6TA-830 | 1996.01-1998.01 | |
| CASE | COTTON PICKERS | 2155 | 6TA-830 | 1996.01-1998.01 | |
| CASE | TRACTORS | 1896 | 6-590/6-359 Diesel | 1984.01-1989.01 | |
| CASE | TRACTORS | 2055 | - | 1990.01- | |
| CASE | TRACTORS | 2090 | 6-504 Diesel | 1978.01-1988.01 | |
| CASE | TRACTORS | 2094 | 6-504 Diesel | 1983.01-1988.01 | |
| CASE | TRACTORS | 2096 | 6-359 Diesel | 1985.01-1990.01 | |
| CASE | TRACTORS | 2290 | 6-504 Diesel | 1978.01-1988.01 | |
| CASE | TRACTORS | 2294 | 504BD/6T-590 Diesel | 1983.01-1987.01 | |
| CASE | TRACTORS | 2390 | 504 Diesel | 1978.01-1988.01 | |
| CASE | TRACTORS | 2394 | 504BD/6T-590 Diesel | 1983.01-1987.01 | |
| CASE | TRACTORS | 2470 | 504 Diesel | 1979.01-1988.01 | |
| CASE | TRACTORS | 2590 | 504 Diesel | 1980.01-1983.01 | |
| CASE | TRACTORS | 2594 | 504BD/6T-590 Diesel | 1983.01-1987.01 | |
| CASE | TRACTORS | 2670 | 504 Diesel | 1979.01-1988.01 | |
| CASE | TRACTORS | 2870 | 6-674 Diesel | 1979.01-1988.01 | |
| CASE | TRACTORS | 3294 | 6-504 Diesel | 1983.01-1985.01 | |
| CASE | TRACTORS | 3394 | 6-504 Diesel | 1985.01-1988.01 | |
| CASE | TRACTORS | 3594 | 6-504 Diesel | 1986.01-1988.01 | |
| CASE | TRACTORS | 4490 | 6-504 Diesel | 1984.01-1988.01 | |
| CASE | TRACTORS | 4494 | 6-504 Diesel | 1984.01-1987.01 | |
| CASE | TRACTORS | 4690 | 6-504 Diesel | 1984.01-1988.01 | |
| CASE | TRACTORS | 4694 | 6-504 Diesel | 1984.01-1990.01 | |
| CASE | TRACTORS | 4890 | 6-674 Diesel | 1984.01-1988.01 | |
| CASE | TRACTORS | 4894 | 6-674 Diesel | 1986.01-1990.01 | |
| CASE | TRACTORS | 4994 | - | 1986.01-1990.01 | |
| CASE | TRACTORS | 7110 | 6-505 | 1987.01-1993.01 | |
| CASE | TRACTORS | 7120 | 6-505 | 1987.01-1993.01 | |
| CASE | TRACTORS | 7130 | 6-505 | 1987.01-1993.01 | |
| CASE | TRACTORS | 7140 | 6-505 | 1987.01-1993.01 | |
| CASE | TRACTORS | 7210 | 6-505 Diesel | 1993.01-1996.01 | |
| CASE | TRACTORS | 7220 | 6-505 Diesel | 1993.01-1996.01 | |
| CASE | TRACTORS | 7230 | 6-505 Diesel | 1993.01-1996.01 | |
| CASE | TRACTORS | 7240 | 6-505 Diesel | 1993.01-1996.01 | |
| CASE | TRACTORS | 7250 | 6-505 Diesel | 1993.01-1996.01 | |
| CASE | TRACTORS | 8930 | 505 | 1996.01- | |
| CASE | TRACTORS | 9110 | - | 1986.01-1993.01 | |
| CASE | TRACTORS | 9130 | - | 1986.01-1993.01 | |
| CASE | TRACTORS | 9210. 9230. 9240 | 8.3 | 1990.01-1996.01 | |
| CASE | TRACTORS | 9310 | 8.3 | 1995.01-2000.12 | |
| CASE | TRACTORS | 9330 | 8.3 | 1995.01-2000.12 | |
| DAEWOO | V158T1 | 8 cyl. 500kW | 14.6 | - |
Mehr Informationen
| Gewicht (kg) | 11.055000 |
|---|---|
| Zustand | Neu |
| Die Spannung | 12 V |
| Die Leistung | 4.2 kW |
| Zähnezahl | 10 |
| Drehrichtung | Im Uhrzeigersinn |
| Bemerkungen | Off set drive end bracket, With reduction gear |
